Download
Product Features and Advantages
Flexible Scaling
Up to 50 units in parallel, 5.12kWh–256kWh capacity range
Comprehensive Protection
Short-circuit locking and surge protection for maximum safety
Versatile Installation
Wall, floor, stack, and rack mounting options for optimal space utilization
Intelligent Self-Heating
Operates from -20°C to 55°C (optional feature)
Technical Parameters
| Model | DL5.0C |
| Battery Type | LiFePO₄ |
| Nominal Battery Energy | 5.12 kWh |
| Nominal Capacity | 100Ah |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8–57.6V |
| Recommended Charge & Discharge C Rate | 0.5C |
| Maximum Discharge C rate | 1C |
| Recommended Charge/Discharge Current | 50A |
| Max. Charge/Discharge Current | Charge 75A, Discharge 100A |
| Peak Discharge Current | 110A(15s) |
| Depth of Discharge (DOD) | 90% |
| Net Weight | 49.9kg |
| Dimension [W/D/H] (mm) | 558/545/150 |
| Charging Temp. Range | 0–55°C / -20–55°C (with heating function) |
| Discharging Temp. Range | -20–55°C |
| Communication | CAN/RS485/RS232 |
| Cycle Life * | ≥6000 Cycles |
| Protection Level | IP20 |
| WIFI Module | Optional |
| Expansion | Up to 50 units in parallel |
| Certification & Safety Standard | UN38.3/CE-EMC/IEC62619/CEI-021 |
| Compatible Inverters | SMA/Schneider/Victron energy/Ingeteam/Solis/GoodWe/Growatt/Solplanet/Luxpower/DEYE/Apsystem etc. |
*Test conditions: 0.2C Charging & Discharging.@25°C, 90% DOD
