Product Features and Advantages
Real-Time Monitoring
Supports APP monitoring and remote firmware upgrades
Broad Compatibility
Works with mainstream inverter brands on the market
Safe & Dependable
Equipped with LiFePO₄ cells and an intelligent BMS
Easy Installation
Wall or floor mounting options to save space
Technical Parameters
| TECHNICAL SPECIFICATIONS | Powerbox PRO |
| Battery Type | LiFePO₄ |
| Nominal Battery Energy | 10.24kWh |
| Usable Energy | 9.728kWh |
| Operating Voltage | 44.8–57.6V |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Nominal Power | 5.12kW |
| Peak Power | 10.24kW |
| Recommended Charge & Discharge C Rate | 0.5C |
| Recommended Charge / Discharge Current | 100A |
| Recommended Depth of Discharge (DOD) | 90% |
| Net Weight | 103kg |
| Dimension [WDH] | 555210928mm |
| Charging Temp. Range | 0–55°C |
| Discharging Temp. Range | -20–55°C |
| Communication | CAN / RS485 / RS232 |
| Cycle Life⁽¹⁾ | >6000 Cycles |
| Protection Level | IP65 |
| Expansion | Up to 5 units in parallel |
| Color | White |
| Alarms | Overcharge / Over-discharge / Overcurrent / Overtemperature / Short Circuit |
| Pros | Can be used in both off-grid and hybrid setups, compact design, floor or wall-mounted |
| Certification & Safety Standard | UN38.3 / CE-EMC / IEC62619 / IEC62040 / IEC60730 / UKCA / CEC Accredited |
| Compatible Inverters | SMA / Victron / Ingeteam / Delios / Goodwe / Solis / Deye / SAJ / Volttronic / Sungrow etc. |
[1]Test conditions: 0.2C Charging / Discharging,@25°C,90% DOD.
