Product Features and Advantages
Fast Charge & Discharge
12kW charging / 13.2kW discharging for rapid load response
Wide Compatibility
Compatible with single-phase ES Uniq and three-phase ET LV series inverters, as well as high-power inverters
Real-Time Monitoring
Smart LED display for clear status visibility
Long-Lasting Safety
Reliable LiFePO₄ technology with excellent cycle stability
Technical Parameters
| Technical Data | 14.3K-LV |
| Rated Energy (kWh) | 14.3 |
| Usable Energy (kWh)¹ | ≥13.8 |
| Battery Type | LFP (LiFePO₄) |
| Nominal Voltage (V) | 51.2 |
| Max. Continuous Charging Current (A) | 224 |
| Max. Continuous Discharging Current (A) | 260 |
| Max. Input Power (System) (kW)² | 12 |
| Max. Output Power (System) (kW)² | 12 (13.2 @ 10min) |
| Peak Output Power (System) (kW)² | 20@15s |
| Charging Temperature Range (°C) | 0 |
| Discharging Temperature Range (°C) | -20 |
| Relative Humidity | 5 ~ 85% |
| Max. Operating Altitude (m) | 4000 |
| Communication | CAN, RS485 |
| Weight (kg) | 125 |
| Dimensions (W × H × D mm) | 530 × 885 × 246 (Without the base)530 × 918.6 × 246 (With base included) |
| Optional Function Configuration | Aerosol |
| Ingress Protection | IP20 |
| Ambient Temperature | 0 |
| Max. Storage Time | 12 months (-20 |
| Mounting Method | Floor-Mounted, Wall-Mounted |
| Standard and Certification | |
| Safety | IEC 62619, IEC 63056, IEC 60730-1 |
| EMC | EN IEC 61000-4-1, EN IEC 61000-4-2, EN IEC 61000-4-3, EN IEC 61000-4-4 |
| Transportation | UN38.3, ADR, MSDS |
*1: Test conditions, 100% DOD(cell 2.85~3.6V voltage range), 0.2P charge & discharge at 25 ± 2°C for battery system at the beginning of life. Usable energy is defined by its initial design value. Actual available energy may vary depending on charge / discharge rate, environmental conditions(e.g. temperature), transport and storage factors
*2: Max.Input Power / Max.Output Power / Peak.Output Power derating will occur related to Temperature and SOC
