Product Features and Advantages
Intelligent Control
Remote diagnosis and updates via inverter, automatic restart after undervoltage
Safe & Reliable
Utilizes LiFePO₄ technology with high cycle stability
Configurable Design
Modular design supports parallel operation
Simple & Efficient
Minimalist modern design with plug-and-play wiring
Technical Parameters
| Technical Data | D5.0 |
| Usable Energy (kWh)¹ | 5 |
| Cell Type | LFP (LiFePO₄) |
| Nominal Voltage (V) | Charge: 435; Discharge: 380 |
| Output Voltage (V) | 320 – 480 |
| Nominal Power (kW)² | 3 |
| Peak Power² | 5kW, 10s |
| Operating Temperature Range (°C) | Charge: 0 – +53; Discharge: -20 – +53 |
| Relative Humidity | 0 - 95% |
| Max. Operating Altitude (m) | 4000 |
| Communication | CAN |
| Weight (kg) | 52 |
| Dimensions (W × H × D mm) | 700 × 380 × 170 |
| Ingress Protection Rating | IP66 |
| Mounting Method | Floor stacked / Wall-mounted |
| Standard and Certification | |
| Safety | IEC62619, IEC60730, VDE2510-50, CE, CEC |
| EMC | CE, RCM |
| Transportation | UN38.3 |
*1: Test conditions,100% DOD,0.2C charge & discharge at +25 ±3°C for battery system at beginning life. System Usable Energy may vary with different Inverter.
*2: Power derating will occur related to Temperature and SOC
*3: All pictures shown are for reference only. Actual appearance may vary.
Smart energy solutions for various scenarios
Secure, scalable, and efficient solutions for home and outdoor energy management.
Home energy independence
Solar efficiency on the balcony is improved
Outdoor travel and emergency preparedness
Commercial and industrial energy storage
Centralized large-scale energy storage
